Ctrl Command get_startstop_info
Function Provides information about internal and External Starts and External Stops since the last
call of get_startstop_info. Also provided are the current External Start and External Stop
levels, the status and signal level of the Laser Control Signals, and possible transmission
errors to and from the attached scan system.
Call
StartStopInfo = get_startstop_info()
Result Info signal.
As an unsigned 32-bit value.
Bit #0
(LSB)
= 1: An internal start has been executed (by execute_list or similar) since
the last call of get_startstop_info.
Bit #1 = 1: An External Start has been executed (by /START, /START2, /Slave-
START, simulate_ext_start or simulate_ext_start_ctrl) since the last
call of get_startstop_info.
Bit #2 = 1: An internal stop has been executed (by stop_execution) since the last
call of get_startstop_info.
Bit #3 = 1: An External Stop has been executed (by /STOP, /STOP2, /Slave-STOP or
simulate_ext_stop) since the last call of get_startstop_info.
Bit #4 Ext-stop status (= logical AND operation of the signals /STOP, /STOP2, /Slave-
STOP and simulate_ext_stop, see Figure 68):
= 1: No stop signals are currently present at the input ports or
the input ports are not connected.
= 0: There is a stop signal at least at one of the input ports.
Bit #5 DLL 619:
= 1: The timeout with wait_for_timestamp_counter_mode and
wait_for_timestamp_counter_long.
Bit #6 Reserved.
Bit #7 Reserved.
Bit
#8 Reserved.
Bi
t #9 = 1: The Laser Control Signalsare globally enabled, see Chapter 7.4.1
”Enabling, Activating and Switching Laser Control Signals”,
page 184. See also set_laser_control.
Bit #10 = 1: The TTL Laser Control Signals at the LASER1 and LASER2 output ports
are active-LOW (the signal level can be defined by set_laser_control).
Bit #11 = 1: Since the last call of get_startstop_info, at least one External Start
has failed (more External Starts were triggered than could be
simultaneously held in the 8-start wait loop).
Bit #12 Ext-Start status (= logical AND operation of the signals /START, /START2 and
/Slave-START, see Figure 68):
= 1: No start signals are currently present at the input ports or
the input ports are not connected.
= 0: A start signal is present at least at one of the input ports.
Bit #13 = 1: The TTL laser control signal at the LASERON output port is active-LOW
(the signal level can be defined by set_laser_control).
