Ctrl Command set_jump_table
Function Reads the Jump Delay table with 1024 unsigned 16-bit values stored at the supplied PC
address and loads them onto the board as the Jump Delay table (see notes for
get_jump_table).
Call ErrorCode = set_jump_table( Addr )
Parameters Addr PC Address of a 2048-byte area of PC main memory.
Result Error code.
As an unsigned 32-bit value.
0 No error.
1 Busy error: board BUSY list execution status or
INTERNAL-BUSY list execution status (get_last_error return code RTC6_BUSY ).
4 Verify error: DSP memory error.
11 RTC6 board driver error.
Comments • set_jump_table is not executed (get_last_error return code RTC6_BUSY ), if:
– the BUSY list execution status is set
– the INTERNAL-BUSY list execution status is set
• set_jump_table is even executed, if:
– a list has been paused by set_wait (PAUSED list execution status set)
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
Reference get_jump_table, load_jump_table_offset
