Ctrl Command eth_set_port_numbers
Function Saves the UDP ports for board searches ( UDPsearch ) and exclusive connections ( UDPexcl ) as
well as the TCP port into the Flash Memory of the RTC6 Ethernet Board.
Call Result = eth_set_port_numbers( UDPsearch, UDPexcl, TCP )
Parameters UDPsearch UDP port for board searches.
As an unsigned 32-bit value.
Allowed value range: [0…65,535].
Out-of-range values are clipped.
UDPexcl UDP port for exclusive connections.
As an unsigned 32-bit value.
Allowed value range: [0…65,535].
Out-of-range values are clipped.
TCP TCP port for exclusive connections.
As an unsigned 32-bit value.
Allowed value range: [0…65,535].
Out-of-range values are clipped.
Result Error code.
As an unsigned 32-bit value.
0: Success: OK.
1: Error: No access to the RTC6 Ethernet Board.
get_last_error return code RTC6_ACCESS_DENIED .
2: Error: No RTC6 Ethernet Board.
get_last_error return code RTC6_TYPE_REJECTED .
3: Error: Programming the Flash Memory is not possible.
The RTC6 Ethernet Board is possibly busy.
get_last_error return code RTC6_BUSY or RTC6_FLASH_ERROR .
Comments • Prerequisites for eth_set_port_numbers:
– No list must currently be executed on the RTC6 Ethernet Board.
– The RTC6 Ethernet Board must be entered in the RTC6 board management.
– The RTC6 Ethernet Board must have been acquired.
• If 0 is specified for a parameter, it is not overwritten.
• Saved parameters are not used until the RTC6 Ethernet Board has been restarted.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 606, OUT 606, RBF 611.
References eth_get_port_numbers
