Ctrl Command set_input_pointer
Function Opens the RTC6 List Memory for writing with list commands and sets the input pointer to
the specified absolute address in RTC6 List Memory (“List 1” or “List 2”).
Call set_input_pointer( Pos )
Parameters Pos Position (absolute memory address) of the input pointer.
[0…(2
23
–1)].
As an unsigned 32-bit value.
Comments • The next list command is stored at the specified address and all further list commands
at the subsequent addresses in the selected list.
• set_input_pointer performs basically like set_start_list_pos (see comments there).
But set_input_pointer sets the input pointer based on a specified absolute memory
address, whereas set_start_list_pos uses a specified list number and a relative
memory address.
• For Pos  Mem1 + Mem2 (see config_list), Pos is set to 0.
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_start_list_pos, get_input_pointer
