Scanlab RTC6 PCIe Board - Set_Mark_Speed; Set_Mark_Speed_Ctrl

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
681
innovators for industry
Delayed Short
List Command
set_mark_speed
Function Sets the mark speed for the Vector Commands and “Arc” Commands.
Call set_mark_speed( Speed )
Parameters Speed Marking speed. In Bits/ms.
As a 64-bit IEEE floating point value.
Allowed value range: [1.6…800000.0].
Out-of-range values are clipped to the boundary values.
Comments • By default a mark speed of 1,000 bits/ms is preset.
• The specified mark speed is used for all [*]mark[*] Commands and “Arc” Commands
until a new value is specified.
• The actual mark speed v
mark
in the image plane in m/s is derived from the specified
Speed value [bits/ms] and the calibration factor K [Bits/mm] as follows:
v
mark
= Speed / K
The calibration factor K can be queried from the correction table by get_table_para or
get_head_para.
• set_mark_speed is also available as control command set_mark_speed_ctrl.
RTC4RTC6 Unchanged functionality.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified Speed value by 16.
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References mark_abs, mark_rel, set_jump_speed, set_mark_speed_ctrl
Ctrl Command set_mark_speed_ctrl
Function Like set_mark_speed, but a control command.
Call set_mark_speed_ctrl( Speed )
Parameters Speed Like set_mark_speed.
Comments • set_mark_speed_ctrl is not executed (get_last_error return code RTC6_BUSY ), if:
– the BUSY list execution status is set
• set_mark_speed_ctrl is even executed, if:
– a list has been paused by set_wait (PAUSED list execution status set)
– the INTERNAL-BUSY list execution status is set
RTC4RTC6 New command.
In RTC4 Compatibility Mode: like set_mark_speed.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_mark_speed, set_jump_speed, set_jump_speed_ctrl
