Scanlab RTC6 PCIe Board - Set_Delay_Mode_List

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
629
innovators for industry
JumpLengthLimit 0…(2
32
–1) Jump length limit. In bits.
JumpLengthLimit > 0 enables “Variable
Jump Delays“ mode.
If the jump vector is longer than this value, then the
fixed Jump Delay (see set_scanner_delays) is
inserted. For all shorter jump lengths, a linearly
interpolated “Variable Jump Delay” (page 148)
between MinJumpDelay and the Jump Delay is
calculated and inserted, see Figure 36.
JumpLengthLimit = 0 disables “Variable
Jump Delays“ mode.
As an unsigned 32-bit value.
RTC4RTC6 Unchanged functionality. In addition: extended value range.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for JumpLengthLimit
by 16. The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_scanner_delays, load_varpolydelay, set_delay_mode_list
Ctrl Command set_delay_mode
Multiple List
Command
set_delay_mode_list
Function Like set_delay_mode, but a list command.
Call set_delay_mode_list( VarPoly, DirectMove3D, EdgeLevel, MinJumpDelay,
JumpLengthLimit )
Parameters VarPoly Like set_delay_mode.
DirectMove3D Like set_delay_mode.
EdgeLevel Like set_delay_mode.
MinJumpDelay Like set_delay_mode.
JumpLengthLimit Like set_delay_mode.
Comments • See set_delay_mode.
• set_delay_mode_list requires two list storage positions.
• set_delay_mode_list is executed as two undelayed short list commands.
• Any still-pending delayed short list command is executed first.
RTC4RTC6 New command.
RTC4 Compatibility Mode: see set_delay_mode.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_delay_mode
