set_angle_list
Function Like set_angle, but a list command.
Call set_angle_list( HeadNo, Angle, at_once )
Parameters HeadNo Like set_angle. However, HeadNo = 4 is not available.
Angle Like set_angle.
at_once Determines when the defined transformation becomes effective.
As an unsigned 32-bit value.
= 0: The transformation settings are only accumulated and intermediately
stored, but the transformation is not processed as long as this is not
activated by another coordinate transformation (for example, by a list
command with at_once = 1 or a corresponding control command).
= 1: The transformation is immediately calculated (including all
transformation settings that were accumulated until then) and
processed prior to the next list command. If necessary,
Signals for “Laser Active” Operation are switched off in advance.
= 2: The transformation settings are only accumulated and intermediately
stored (as with at_once = 0). However, The transformation is
immediately calculated (including all transformation settings that
were accumulated and intermediately stored until then) and applied
to the current position when the next jump_abs or jump_rel
(only if no list is currently being executed: also goto_xy or
goto_xyz) is executed.
= 3: Like at_once = 1, but the Laser Control Signals remain unaffected.
> 3: Like at_once = 2.
Comments • –
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_angle
