10 RTC6 Commands
458
innovators for industry
Undelayed
Short List
Command
if_not_cond
Function Conditional command execution:
if_not_cond immediately executes the directly following list command, if the current
IOvalue at the EXTENSION 1 socket connector’s 16-bit digital input port does not meet the
following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are not 1 or the bits specified in Mask0 are not 0 ).
Otherwise, this list command is skipped.
Call if_not_cond( Mask1, Mask0 )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 See Mask1 .
Comments • See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References if_cond, if_pin_cond, if_not_pin_cond
