Ctrl Command measurement_status
Function Returns:
• Status of a measurement started by set_trigger/set_trigger4/set_trigger8
• Current position of the measurement counter
Call measurement_status( &Busy, &Pos )
Returned
parameter
values
Busy Measurement status.
As a pointer to an unsigned 32-bit value.
> 0: A measurement session is currently in progress.
= 0: No measurement session is currently in progress.
Pos Current position of the measurement counter (within the RTC6
measurement data memory) [0…max. channel size, see
set_trigger/set_trigger4/set_trigger8].
As a pointer to an unsigned 32-bit value.
Comments • If a measurement session started by set_trigger/set_trigger4/set_trigger8 is no
longer active, then Pos +1 indicates the number of recorded data pairs up to
termination
([0…max. channel size, see set_trigger/set_trigger4/set_trigger8]).
• Pos = 2
32
–1 indicates that data recording still has not occurred after
load_program_file.
• Stored data can be queried with get_waveform.
• The status of the measurement recording is reset by (see set_trigger comments):
– set_trigger( Period = 0 )
– set_trigger4( Period = 0 )
– set_trigger8( Period = 0 )
– stop_trigger
– stop_execution
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_trigger, set_trigger4,
set_trigger8
