Scanlab RTC6 PCIe Board - Set_Laser_Mode; Set_Laser_Off_Default

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
672
innovators for industry
Ctrl Command set_laser_mode
Function Sets the laser mode of the RTC6.
Call set_laser_mode( Mode )
Parameters Mode = 0: CO
2
Mode.
= 1: YAG Mode 1.
= 2: YAG Mode 2.
= 3: YAG Mode 3.
= 4: Laser Mode 4.
= 5: YAG Mode 5.
= 6: Laser Mode 6.
As an unsigned 32-bit value.
Comments • The available Laser Control Signals depend on the set laser mode,
see also Chapter 7.4 ”Laser Control”, page 184.
RTC4RTC6 Additional laser modes, for example, YAG Mode 5, Laser Mode 6 and Pulse Picking.
Otherwise, unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_laser_control, set_laser_pulses_ctrl, set_laser_pulses, set_laser_timing,
set_firstpulse_killer, set_firstpulse_killer_list, set_standby, set_standby_list,
set_qswitch_delay, set_qswitch_delay_list
Ctrl Command set_laser_off_default
Function Sets the default output value for the ANALOG OUT1 and ANALOG OUT2 output ports, as
well as for the 8-bit digital output port of the RTC6.
Call set_laser_off_default( AnalogOut1, AnalogOut2, DigitalOut )
Parameters AnalogOut1 12-bit value for analog output port ANALOG OUT1, see also Section ”12-
Bit Analog Output Port 1 and 2”, page 74. As an unsigned 32-bit value.
Higher bits are ignored (exception: AnalogOut1/AnalogOut2 = “–1“, see
comments for set_port_default).
AnalogOut2 12-bit value for analog output port ANALOG OUT2.
See AnalogOut1 .
DigitalOut 8-bit value for the 8-bit digital output port, see also Section ”8-Bit Digital
Output Port”, page 81.
As an unsigned 32-bit value. Higher bits are ignored (exception:
DigitalOut = “–1“, see comments for set_port_default).
Comments • The default values can also be defined by set_port_default.
See also all comments there.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified values for AnalogOut1 and
AnalogOut2 by 4.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_port_default
