Ctrl Command set_jump_mode
Function Enables and activates or disables and deactivates Jump Mode for 2D jumps and sets the
related parameters.
Prerequisite Enabling is only possible if a jump-tuning-equipped intelliSCAN (with
scan system firmware version  2078) is attached to at least one of the two scan head
connectors. Otherwise, set_jump_mode has no effect.
Call ErrorCode = set_jump_mode( Flag, Length, VA1, VA2, VB1, VB2, JA1, JA2, JB1, JB2 )
Parameters Flag Switching flag.
As a signed 32-bit value.
Allowed values:
= –1: Jump Mode is disabled. Afterward, switching the Flag by
set_jump_mode_list is no longer possible.
= 0: Jump Mode is enabled but deactivated.
Afterwards it is also possible to switch the flag
by set_jump_mode_list.
= 1: Jump Mode is enabled and activated.
Afterwards it is also possible to switch the flag
by set_jump_mode_list.
Length Limit of the jump length (per axis) under which 2D jumps – even with
activated Jump Mode – are performed in vector mode.
As an unsigned 32-bit value.
VA1
VA2
VB1
VB2
JA1
JA2
JB1
JB2
Numbers of the tunings that should be used for jump execution in
Jump Mode:
V: The Vector tuning that is set at the end of a 2D jump.
J: The Jump tuning that is set at the beginning of a 2D jump.
A First scan head connector.
B Second scan head connector.
1: x axis (STATUS channel, Galvanometer scanner 2).
2: y axis (STATUS1 channel, Galvanometer scanner 1).
Allowed values:
= – 1: Tuning is neither checked nor used.
= 0…3: After passing a check, tuning is used for Jump Mode.
The allowed value range also depends on the number
of tunings with which the attached scan system is equipped.
As a signed 32-bit value.
