10 RTC6 Commands
663
innovators for industry
Result Error code.
As a signed 32-bit value.
0 No error: Flag successfully switched to 0
(Jump Mode deactivated, vector mode activated).
1 No error: Flag successfully switched to 1
(Jump Mode activated, vector mode deactivated).
–1 Flag successfully switched to –1
(Jump Mode deactivated and disabled).
–2 Busy error: board BUSY list execution status or
INTERNAL-BUSY list execution status
(get_last_error return code RTC6_BUSY ).
–3 Board not responding: no program loaded or PCI error
(get_last_error return code RTC6_TIMEOUT ).
–4 Access error: board reserved for another user program
(get_last_error return code RTC6_ACCESS_DENIED ).
> 1 Did not pass the check (see also notes). Flag is set to –1
(Jump Mode deactivated and disabled).
The following is returned:
Byte #0 = 255.
Byte #1 = Error code for first scan head connector.
Byte #2 = Error code for second scan head connector.
Byte #3 = 0.
Whereby error code:
=1: x axis (galvanometer scanner 2) not responding or
no intelliSCAN (with scan system firmware version  2078) attached.
=2: y axis (galvanometer scanner 1) not responding or
no intelliSCAN (with scan system firmware version  2078) attached.
=4: no correction table assigned.
=8: incorrect tuning number(s): incorrect type or unsuitable for
rapid switching.
Ctrl Command set_jump_mode
