Scanlab RTC6 PCIe Board - Set_Io_Cond_List

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
661
innovators for industry
Undelayed
Short List
Command
set_io_cond_list
Function Sets the bits of the 16-bit digital output port on the EXTENSION 1 socket connector that
are set in the parameter MaskSet , if the current IOvalue at the 16-bit digital input port on
the EXTENSION 1 socket connector meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ).
Call set_io_cond_list( Mask1, Mask0, MaskSet )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 Like Mask1 .
MaskSet Like Mask1 .
Comments • set_io_cond_list sets only those bits of the digital output port that are set in the
parameter MaskSet and leaves the other bits unchanged.
• See Section ”16-Bit Digital Input Port and 16-Bit Digital Output Port”, page 78 and
Chapter 9.3.2 ”Conditional Command Execution”, page 295.
Examples
(Pascal)
• Set Bit #4 of the output port (DIGITAL OUT4), if Bit #0 of the input port (DIGITAL IN0)
is set and Bit #1…Bit #3 (DIGITAL IN1…3) of the input port are not set:
set_io_cond_list ($0001, $000E, $0010)
• Always set Bit #15 of the output port (and leave the other bits unchanged):
set_io_cond_list (0, 0, $8000)
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References clear_io_cond_list, write_io_port, write_io_port_mask, get_io_status, read_io_port
