10 RTC6 Commands
751
innovators for industry
Delayed Short
List Command
set_trigger
Function Starts measurement value recording of the specified signals.
Call set_trigger( Period, Signal1, Signal2 )
Parameters Period Measurement period (time interval between 2 data pair recordings).
1 bit equals 10 µs.
Allowed value range: [0…(2
31
–1)].
Bit #30 = 0: Automatic recording stop at the end of the list.
Bit #30 = 1: No automatic recording stop at the end of the list.
Bit #31 = 0: Automatic stop at the max. channel size, see
set_trigger4/set_trigger8.
Bit #31 = 1: Endless recording (circular buffer).
As an unsigned 32-bit value.
Signal1
********
********
********
********
********
********
********
********
********
********
****
Signal type for measurement channel 1.
As an unsigned 32-bit value.
Allowed value range: see below.
0 LASERON signal
1 = laser control signal on. 0 = laser control signal off.
1 StatusAX
Status signal of x axis, first scan head connector.
2 StatusAY
Status signal of y axis, first scan head connector.
3 Reserved.
4 StatusBX
Status signal of x axis, second scan head connector.
5 StatusBY
Status signal of y axis, second scan head connector.
6 Reserved.
7 SampleX
Cartesian control value for the x axis
(= up to 4 in 7.3.6, page 181).
8 SampleY
Cartesian control value for the y axis
(= up to 4 in 7.3.6, page 181).
9 SampleZ
Cartesian control value for the z axis
(= up to 4 in 7.3.6, page 181).
