RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
752
innovators for industry
Parameters
(cont’d)
Signal1
(cont’d)
10 SampleAX_Corr
Corrected x axis control value for the first scan head connector
(= up to 8 in 7.3.6, page 181).
11 SampleAY_Corr
Corrected y axis control value for the first scan head connector
(= up to 8 in 7.3.6, page 181).
12 SampleAZ_Corr
Corrected z axis control value, if xy are connected to the first scan head
connector (= up to 8 in 7.3.6, page 181).
Identical to the effective output value for the z axis.
13 SampleBX_Corr
Corrected control value for the x axis, second scan head connector
(= up to 8 in 7.3.6, page 181).
14 SampleBY_Corr
Corrected control value for the y axis, second scan head connector
(= up to 8 in 7.3.6, page 181).
15 SampleBZ_Corr
Corrected z axis control value, if xy are connected to the second
scan head connector (= up to 8 in 7.3.6, page 181).
Identical to the effective output value for the z axis.
16 StatusAX+LASERON signal
StatusAX for laser control signal on.
–524,288 for laser control signal off.
17 StatusAY+LASERON signal
StatusAY for laser control signal on.
–524,288 for laser control signal off.
18 StatusBX+LASERON signal
StatusBX for laser control signal on.
–524,288 for laser control signal off.
19 StatusBY+LASERON signal
StatusBY for laser control signal on.
–524,288 for laser control signal off.
