Scanlab RTC6 PCIe Board - Page 753

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
753
innovators for industry
Parameters
(cont’d)
Signal1
(cont’d)
20 SampleAX_Out
Actual output value for the x axis, first scan head connector
(= up to 9 in 7.3.6, page 181).
Not usable for z axis output values.
21 SampleAY_Out
Actual output value for the y axis, first scan head connector
(= up to 9 in 7.3.6, page 181).
Not usable for z axis output values.
22 SampleBX_Out
Actual output value for the for the x axis, second scan head connector
(= up to 9 in 7.3.6, page 181).
Not usable for z axis output values.
23 SampleBY_Out
Actual output value for the y axis, second scan head connector
(= up to 9 in 7.3.6, page 181).
Not usable for measuring z axis output values.
24 Laser control parameter of “Automatic Laser Control“
See set_auto_laser_control.
25 SampleAX_Trans
Transformed control value for the x axis, first scan head connector
(= up to 7 in 7.3.6, page 181).
26 SampleAY_Trans
Transformed control value for the y axis, first scan head connector
(= up to 7 in 7.3.6, page 181).
27 SampleAZ_Trans
Transformed z axis control value, if xy are connected to the first
scan head connector (= up to 7 in 7.3.6, page 181).
28 SampleBX_Trans
Transformed control value for the x axis, second scan head connector
(= up to 7 in 7.3.6, page 181).
29 SampleBY_Trans
Transformed control value for the y axis, second scan head connector
(= up to 7 in 7.3.6, page 181).
30 SampleBZ_Trans
Transformed z axis control value, if xy are connected to the second
scan head connector (= up to 7 in 7.3.6, page 181).
Delayed Short
List Command
set_trigger
