Parameters
(cont’d)
Signal1
(cont’d)
31 Laser control parameter of “vector-controlled laser control”
See set_vector_control.
32 Focus shift
See set_vector_control, set_defocus, set_defocus_list.
33 12-bit output value at the ANALOG OUT1 output port
See set_vector_control and Chapter 9.1.4 ”12-Bit Analog Output Port
1 and 2”, page 283.
34 12-bit output value at the ANALOG OUT2 output port
See set_vector_control and Chapter 9.1.4 ”12-Bit Analog Output Port
1 and 2”, page 283.
35 Output value at the 16-bit digital output port
See set_vector_control and Chapter 9.1.1 ”16-Bit Digital Output Port”,
page 282.
36 Output value at the 8-bit digital output port
See set_vector_control and Chapter 9.1.2 ”8-Bit Digital Output Port”,
page 283.
37 Pulse length (PulseLength) of the Laser Control Signals LASER1 and
LASER2
See set_vector_control.
38 Output period (HalfPeriod) of the Laser Control Signals LASER1 and
LASER2
See set_vector_control.
39 FreeVariable0
40 FreeVariable1
41 FreeVariable2
42 FreeVariable3
Delayed Short
List Command
set_trigger
