Scanlab RTC6 PCIe Board - Set_Trigger8

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
761
innovators for industry
Delayed Short
List Command
set_trigger8
Function Starts the measurement value recording of the specified measurement signals
(has the same effect as set_trigger, but with up to 8 simultaneous measurement signals).
Call set_trigger8( Period, Signal1, Signal2, Signal3, Signal4,
Signal5, Signal6, Signal7, Signal8 )
Parameters Period Like set_trigger.
Signal1 Like set_trigger.
Signal2 Like set_trigger.
Signal3 Like set_trigger.
Signal4 Like set_trigger.
Signal5 Like set_trigger.
Signal6 Like set_trigger.
Signal7 Like set_trigger.
Signal8 Like set_trigger.
Comments • See comments for set_trigger.
• 2
22
entries per measurement channel are available with set_trigger8.
The measurement value recording ends automatically with 2
22
data octuples.
• A currently running measured value recording is terminated by
(no matter which of the 3 commands started it):
– set_trigger( Period = 0)
– set_trigger4( Period = 0)
– set_trigger8( Period = 0)
• Other than set_trigger and set_trigger4, set_trigger8 does not automatically
increase the memory area for data recording by merging unused channels. A maximum
of 2
22
entries per measuring channel is always recorded.
• The measurement value counter is reset when a new measurement value recording is
started again by:
– set_trigger( Period > 0)
– set_trigger4( Period > 0)
– set_trigger8( Period > 0)
Already existing data are overwritten with new data.
See also the corresponding comments under set_trigge
r.
• A
s with set_trigger/set_trigger4, get_waveform/get_waveform_offset can be used
to transfer the recorded values to the PC.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 635, OUT 636.
References set_trigger, set_trigger4, stop_trigger, get_waveform, get_waveform_offset
