Scanlab RTC6 PCIe Board - Set_Trigger4

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
760
innovators for industry
Delayed Short
List Command
set_trigger4
Function Starts the measurement value recording of the specified measurement signals
(has the same effect as set_trigger, but with up to 4 simultaneous measurement signals).
Call set_trigger4( Period, Signal1, Signal2, Signal3, Signal4 )
Parameters Period Like set_trigger.
Signal1 Like set_trigger.
Signal2 Like set_trigger.
Signal3 Like set_trigger.
Signal4 Like set_trigger.
Comments • See comments for set_trigger.
• 2
23
entries per measurement channel are available with set_trigger4, if all 4 signals
are within the allowed range (see set_trigger). The measurement value recording ends
automatically with 2
23
data quadruples.
• If Signal 3 and Signal 4 are not allowed (see set_trigger), set_trigger4 is synonymous
with set_trigger. The memory areas of Signal 3 and Signal 4 are added to the memory
areas of Signal 1 and Signal 2. This allows recording of 2
24
data pairs. The measured
value recording ends automatically with 2
24
data pairs.
• If only Signal 1 is within the permissible range, the memory areas of all 4 channels are
merged into a single one. With this up to 2
25
data values can be recorded. The
measured value recording ends automatically at 2
25
data values.
• An active measured value recording is terminated by
(no matter which of the 3 commands started it):
– set_trigger( Period = 0)
– set_trigger4( Period = 0)
– set_trigger8( Period = 0)
• If set_trigger( Period > 0) or set_trigger4( Period > 0) is used to start a new
measurement value recording, then the measurement value counter is reset. Existing
data is overwritten with new measurement values. See also the corresponding
comments for set_trigger.
• As with set_trigger/set_trigger4, get_waveform/
get_waveform_offset ca
n be used
to transfer the recorded values to the PC.
RTC4RTC6 New command.
RTC5RTC6 Basically unchanged functionality.
Increased memory area for data recordings by merging unused channels, endless
recording.
Version info Available as of DLL 600, OUT 600, RBF 600.
Last change DLL 610, OUT 610, RBF 615: see set_trigger.
References set_trigger, set_trigger8, stop_trigger, get_waveform, get_waveform_offset
