Ctrl Command set_char_table
Function Stores the absolute start address of a command list in the internal management table for
indexed text strings.
Call set_char_table( Index, Pos )
Parameters Index Index of the indexed text string whose starting address Pos should be entered
in the management table. As an unsigned 32-bit value.
Allowed value range: [0…41]).
The same ordering applies as for the load_text_table command:
= 0…9: Digits for marking the time and date [0…9].
= 10…21: Months [January…December].
= 22…28: Days-of-the-week [Sunday…Saturday].
= 29: Blank character for marking serial numbers.
= 30…39: Digits for marking serial numbers [0…9].
= 40: Text for “a.m.”.
= 41: Text for “p.m.”.
Pos Absolute start address.
As an unsigned 32-bit value.
Allowed value range: [0…(2
23
–1)].
Comments • set_char_table is synonymous with set_text_table_pointer.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_text_table_pointer
