RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
550
Normal List
Command
micro_vector_rel_3d
Function Moves the output point (of the laser focus) by a “Hard Jump” (without split-up into
Microsteps) directly from the current position to the specified position (relative coordinate
values) within the 3D Image Field.
Restriction If the Option “3D” is not enabled or no 3D correction table has been assigned (see
select_cor_table), then micro_vector_rel_3d has the same effect as micro_vector_rel.
Call
micro_vector_rel_3d( dX, dY, dZ, LasOn, LasOff )
Parameters
dX
Relative x coordinate of the micro vector end point. In bits.
Otherwise, like wie
X
von micro_vector_abs_3d
.
dY
Relative y coordinate of the micro vector end point. In bits.
Otherwise, like wie
Y
von micro_vector_abs_3d
.
dZ
Relative z coordinate of the micro vector end point. In bits.
Otherwise, like wie
Z
von micro_vector_abs_3d
.
LasOn
Like
LasOn
from micro_vector_abs_3d.
LasOff
Like
LasOff
from micro_vector_abs_3d.
Comments • The coordinates for the micro vector end point are to be supplied as relative
coordinates with respect to the current position. Otherwise, micro_vector_rel_3d is
identical to micro_vector_abs_3d (see comments there).
• The Microvector is always executed as a “Hard Jump”.
RTC4RTC6 New command.
RTC4 Compatibility Mode: see micro_vector_abs_3d.
RTC5RTC6 Unchanged functionality.
RTC5 Compatibility Mode: see micro_vector_abs_3d.
Version info Available as of DLL 600, OUT 600, RBF 600.
References micro_vector_abs_
3d, micro_vector_rel
Ctrl Command move_to
Comments • move_to is described in the manual “Installation and Operation RTC Step Motor
Extension for the RTC4 and RTC5 PC interface boards” (available in English only).
• move_to has been introduced for the “RTC4 STEP MOTOR EXTENSION”
extension board (#112097).
• move_to is not supported by “RTC5/6 varioSCAN 40 FLEX Extension” extension board
(#128683). See also Chapter 2.8.7 ”Extension Board “RTC5/6 varioSCAN FLEX
Extension””, page 46.
