Scanlab RTC6 PCIe Board - Set_Wobbel_Vector_2; Set_Zoom; Set_Zoom_List

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
780
innovators for industry
Undelayed
Short List
Command
set_wobbel_vector_2
Function Like set_wobbel_vector. However, only for set_wobbel_control( Ctrl = 8 ).
Call set_wobbel_vector_2( dTrans, dLong, Period, dPower, dPower2, Ctrl )
Parameters dTrans Like set_wobbel_vector.
dLong Like set_wobbel_vector.
Period Like set_wobbel_vector.
dPower Microstep of the relative laser power. Refers to ANALOG OUT1.
As a 64-bit IEEE floating point value.
Allowed value range: [–1.0…+1.0].
dPower2 Microstep of the relative laser power. Refers to ANALOG OUT2.
As a 64-bit IEEE floating point value.
Allowed value range: [–1.0…+1.0].
Ctrl Reserved.
As an unsigned 32-bit value.
Out-of-range values are clipped to the boundary values.
Comments • set_wobbel_vector_2 can only be used with set_wobbel_control( Ctrl = 8 ).
• Like set_wobbel_vector.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 631, OUT 632.
References set_wobbel_vector
Ctrl Command set_zoom
Call set_zoom( Zoom )
Comments • This command is described, for example, in the manual for the intelliWELD II FT.
Undelayed
Short List
Command
set_zoom_list
Call set_zoom_list( Zoom )
Comments • This command is described, for example, in the manual for the intelliWELD II FT.
