Scanlab RTC6 PCIe Board - Page 779

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
779
innovators for industry
Comments
(cont’d)
• If the wobbel shape gets switched off while the Wobbel Mode remains active, then the
shape automatically switches to Mode = 1 (horizontal figure-8).
• The Wobbel Mode with “freely definable wobbel shapes” also needs to be switched on
by set_wobbel_mode.
• Variable laser power for wobbel shapes cannot be combined with variable laser power
for automatic or vector-based laser control (parameterized [*]mark[*] Commands).
Wobbel variation overwrites other variations if the respective Ctrl parameters are
identical. Though unidentical Ctrl parameters are allowed, they serve no practical
purpose.
• When defining “freely definable wobbel shapes” make sure that the Microsteps of
each individual wobbel vector does not exceed the maximum positioning speed
significantly! Otherwise, a galvanometer scanner overheating may occur, see also
Chapter 8.4.1 ”Wobbel Shapes – Important Notes on Choosing Appropriate Parameter
Values”, page 234.
• create_dat_file saves a “freely definable wobbel shape”, see comment on page 349.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_multi_mcbsp_in, set_multi_mcbsp_in_list, set_wobbel_control,
set_wobbel_offset, set_wobbel_vector_2
Undelayed
Short List
Command
set_wobbel_vector
