Ctrl Command load_z_table
Function Like load_z_table_20b.
However, for a focus length value l in RTC4 compatibility range [–32,768…+32,767].
Restriction Like load_z_table_no_20b.
Call ErrorNo = load_z_table( A, B, C )
Parameters A Like load_z_table_no.
B Like load_z_table_no.
C Like load_z_table_no.
Result Like load_z_table_no_20b.
Comments • Like load_z_table_no_20b. .
• load_z_table( A, B, C ) is synonymous with load_z_table_no( A, B, C, 0 ) .
RTC4RTC6 Unchanged functionality. In addition: changed value ranges and error codes.
If the correct calibration factors are used (see Chapter ”3D Commands”, page 238), then
the same ABC coefficients can be used on the same 3-axis scan system with the RTC4 and
RTC6 boards.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_z_distance, read_abc_from_file, write_abc_to_file, load_z_table_no,
select_cor_table, load_z_table_20b
