Scanlab RTC6 PCIe Board - List_Jump_Rel_Cond

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
486
innovators for industry
Undelayed
Short List
Command
list_jump_rel_cond
Function Conditional relative list jump: list_jump_rel_cond executes list_jump_rel( Pos ), if the
current IOvalue at the EXTENSION 1 socket connector’s 16-bit digital input port meets the
following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ). Otherwise, the
directly following list command is immediately executed.
Call list_jump_rel_cond( Mask1, Mask0, Pos )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 See Mask1 .
Pos Jump distance [(–2
23
+1)…(2
23
–1)].
As a signed 32-bit value.
Comments • See list_jump_rel.
• Unlike the rules for preventing endless loops (see list_jump_rel), jumps by
list_jump_rel_cond are allowed even if they are to their own address ( Pos = 0), for
example, to wait for confirmation of a signal.
• See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
Examples
(Pascal)
• Wait until Bit #3 of the input port turns HIGH (= loop while the bit is LOW):
list_jump_rel_cond(0, $0008, 0);
• Skip the next two list commands if the state of the input port is xxxx xxxx xxxx 0110 :
list_jump_rel_cond(6, 9, 3);
• See also Section ”Example Code (Pascal)”, page 296.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References list_jump_rel
