Undelayed
Short List
Command
periodic_toggle_list
Function Generates and periodically toggles a signal at an adjustable output port.
Call periodic_toggle_list( Port, Mask, P1, P2, Count, Start )
Parameters Port Output port (0…4, as with set_port_default).
As an unsigned 32-bit value.
Mask Defines the bits to be toggled, (the maximum value depends on the port).
1 = bit is toggled.
0 = bit remains unchanged.
As an unsigned 32-bit value.
P1 Duration of the toggled signal in [10 µs] (> 0, 16 bit max.).
As an unsigned 32-bit value.
P2 Duration of the toggled signal in [10 µs] (> 0, 16 bit max.).
As an unsigned 32-bit value.
Count Number of P1–P2 period repetitions.
As an unsigned 32-bit value.
Start Duration until the first toggling starts in [10 µs].
As an unsigned 32-bit value.
Comments • If an unallowed parameter value is supplied for Port or 0 for P1 or P2 , then
periodic_toggle_list is replaced by a list_nop and a get_last_error return code
RTC6_PARAM_ERROR is generated.
• Mask defines the bits to be toggled. Bits which are set to 1 in Mask are toggled and bits
which are set to 0 remain unchanged. Mask is limited to the maximum allowed value of
the selected port (see also set_port_default). Extra bits are ignored.
• The selected bits are toggled. This state is maintained for P1
 10 µs clock cycles. Then
they are toggled once again and kept stable for P2
 10 µs clock cycles. Users define
the toggle bit start values (“off” state; “on” signal is active-HIGH or active-LOW) by
other standard commands (write_da_x, write_8bit_port, write_io_port, etc.).
These – and (should the situation arise) other queued delayed short list commands –
are executed before periodic_toggle_list.
• The first toggling occurs after Start
 10 µs clock cycles. Toggling is repeated
Count -times. Count = 0 immediately stops an output in progress. The remaining
parameters are then not relevant. If the stop happens in the P1 period (“On”), a toggle
occurs to restore the initial state (“Off”).
• The parameters P1 and P2 are clipped to the value range [0…65,535]. P1 and P2 must
not be 0 at the same time.
• The selected port should not concurrently be used for other outputs such as
“Automatic Laser Control“.
• At a set_end_of_list, stop_execution or external /STOP the periodical signals
continue.
• periodic_toggle_list toggles endless with
Count = 2
32
–1.
• See also Chapter 9.4 ”Periodical I/O Signals”, page 301.
