Ctrl Command set_laser_pulse_sync
Function Switches Pulse Synchronization Mode on (off).
Call set_laser_pulse_sync( Mode, Delay )
Parameters Mode = 0: Switches Pulse Synchronization Mode off.
> 0: Switches Pulse Synchronization Mode on.
As an unsigned 32-bit value.
Delay Delay. In 1/64 µs.
As an unsigned 32-bit value.
Comments • See also Chapter 7.4.11 ”Pulse Synchronization Mode”, page 208.
• See also Section ”“Spot Distance Control””, page 202.
• set_laser_pulse_sync is not executed (get_last_error return code RTC6_BUSY ), if:
– the BUSY list execution status is set
– the INTERNAL-BUSY list execution status is set
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 625, OUT 625, RBF 628.
References –
