Scanlab RTC6 PCIe Board - Get_Rtc_Version

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
421
innovators for industry
Ctrl Command get_rtc_version
Function Returns the version number of the FPGA firmware ( RTC6RBF.rbf ) and information about
enabled options of the RTC6 board.
Call RTCVersion = get_rtc_version()
Result Version number of the FPGA firmware and additional information.
As an unsigned 32-bit value.
Bit #0 (LSB)
…
Bit #7
Version number of the FPGA firmware ( RTC6RBF.rbf ).
Bit #8 = 1: Option Processing-on-the-fly is enabled.
See also Chapter 8.6 ”Processing-on-the-fly”, page 242.
Bit #9 = 1: Option “Second Scan Head Control” is enabled.
See also Section ”2. SCANHEAD Socket Connector”, page 68.
Bit #10 = 1: Option “3D” is enabled.
See also Chapter 8.5.2 ”3D Scan Systems”, page 237.
Bit #11 = 1: Option “LDSA” is enabled (as of DLL 628).
Bit #12 = 1: Option “SCANa“ is enabled (as of DLL 605).
Bit #13 = 1: Option “UFPM“ is enabled (as of DLL 605).
Bit #14 = 1: Option “syncA“ is enabled (as of DLL 607).
Bit #15 Reserved.
Bit #16
…
Bit #23
DSP version number.
Bit #24
…
Bit #31
Subversion number of the FPGA firmware ( RTC6RBF.rbf ).
Comments • The FPGA firmware version numbers are in the range 600…699.
• get_rtc_version ( Bit #0…Bit #7 ) returns values in the range 0…99
(version number – 600).
• The current DSP version number is 3.
• The current FPGA firmware subversion is 0.
• The FPGA firmware version can even be returned after an RTC6_VERSION_MISMATCH or
RTC6_ACCESS_DENIED error. The return value is 0, if no program has yet been loaded.
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_hex_version, get_dll_version
