RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
560
Normal List
Command
para_mark_abs_3d
Function Moves the laser focus at mark speed along a 3D vector from the current position to the
specified position (absolute coordinate values) within the 3D Image Field. Simultaneously
varies the signal parameter selected by set_vector_control linearly to the specified value.
Restriction If the Option “3D” is not enabled or no 3D correction table has been assigned (see
select_cor_table), then para_mark_abs_3d has the same effect as para_mark_abs.
However, split-up into Microsteps is calculated like a 3D command and hence influences
the effective mark speed in the xy plane.
Call
para_mark_abs_3d( X, Y, Z, P )
Parameters
X
Absolute x coordinate of the mark vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456…+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual Image Field for example,
for (enabled) Processing-on-the-fly applications.
Y
Like
X
(analogously).
Z
Like
X
(analogously), except
Allowed value range: [–524,288…+524,287].
P
End value of the signal parameter. As an unsigned 32-bit value. Allowed
values: dependent on the selection made by set_vector_control (
Ctrl
parameter), identical with set_vector_control (
Value
parameter).
Comments • Except for the additional motion in the third dimension, this command functions
similarly to the para_mark_abs command (see comments there).
• Further comments see mark_abs_3d.
• [*]para_mark[*] commands generally do not take Sky Writing into account.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for the x and
y coordinates by 16. The allowed value range decreases accordingly.
For the parameter
P
, see para_jump_abs.
RTC5RTC6 Unchanged functionality.
For the parameter
P
, see para_jump_abs.
Version info Available as of DLL 600, OUT 600, RBF 600.
References mark_abs_3d, set_vector_control, para_mark_abs, pa
ra_mark_rel_3d
