Ctrl Command set_sky_writing
Function Activates Sky Writing Mode 1 and sets the corresponding parameters or switches off
Sky Writing.
Call set_sky_writing( Timelag, LaserOnShift )
Parameters Timelag Like set_sky_writing_para.
LaserOnShift Like set_sky_writing_para.
Comments • set_sky_writing is identical to
set_sky_writing_para( Timelag, LaserOnShift, Nprev, Npost )
with Nprev = approx. (0.15 × Timelag ) and Npost = approx. (0.1 × Timelag ).
• See also information about set_sky_writing_para and Chapter 7.2.4 ”Sky Writing”,
page 160.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility Mode, the RTC6 multiplies the value specified for LaserOnShift by
32. The allowed value range decreases accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_sky_writing_para, set_sky_writing_list
