RTC6 boards
Doc. Rev. 1.0.21 en-US
1 About this Manual
24
1 About this Manual
This manual describes the available SCANLAB
RTC6 boards and their usage for synchronous control
of scan systems, lasers and peripheral equipment.
The main chapters of this manual use the
RTC6 PCIe Board (= “RTC6 PCI Express Board”) to
exemplify. For a product overview, see Chapter 2
”Product Overview”, page 31.
Other RTC6 board variants are described in the
Appendix:
• RTC6 Ethernet Board, see Chapter 16
”Appendix A: The RTC6 Ethernet Board”,
page 876
The manual is a part of the product. Read these
instructions carefully before you proceed with
installing and operating.
In particular, observe all safety guidelines in this
manual. If there are any questions regarding the
contents of this manual, contact SCANLAB, see
Chapter 1.1 ”Manufacturer”.
Keep the manual available for servicing, repairs and
product disposal. This manual should accompany the
product if ownership changes hands.
This manual refers to:
• RTC6 Software Package V1.16.0
The version numbers of the supplied RTC6 DLL and
RTC6 files are indicated in the names of the
corresponding
zip
files, see Section ”Folder RTC6
Files”, page 33.
To identify the version numbers of your files after
installation, use get_dll_version, get_hex_version
and get_rtc_version.
1.1 Manufacturer
SCANLAB GmbH
Siemensstr. 2a
82178 Puchheim
Germany
Tel. +49 (89) 800 746-0
Fax: +49 (89) 800 746-199
info@scanlab.de
www.scanlab.de
DLL file
for 32 bit
user programs
(a)
(a) Software for laser–scan processes, which controls
RTC6 boards based on this
RTC6 DLL file is consistently
denoted as “user program” in this manual.
RTC6DLL.dll
DLL 640
(b)
(b) Abbreviated version in this manual for the Versions.
DLL file
for 64 bit
user programs
(a)
RTC6DLLx64.dll
Program file
for the PCIe-DSP
RTC6OUT.out
OUT 641
(b)
Program file
for the Eth-DSP
RTC6ETH.out
ETH 641
(b)
Firmware file
for the FPGA
RTC6RBF.rbf
RBF 637
(b)
Auxiliary file
RTC6DAT.dat
DAT 604
(b)
