Ctrl Command mcbsp_init_spi
Function No function.
Call mcbsp_init_spi( ClockLevel, ClockDelay )
Parameters ClockLevel = 0: inactive low.
> 0: inactive high.
As an unsigned 32-bit value.
ClockDelay = 0: Clock signal and data bits at the same time.
> 0: Clock signal is delayed a half period.
As an unsigned 32-bit value.
Comments • See Chapter 4.6.6 ”McBSP/ANALOG Socket Connector”, page 84.
RTC4RTC6 New command.
RTC5RTC6 Changed functionality.
• The RTC6 command set contains mcbsp_init_spi, but it has no effect. Execution of it
is refused and the get_last_error return code is RTC6_REJECTED .
• Notes on migrating the source code of RTC5 user programs, etc.: For hardware reasons,
RTC6 boards are no longer configurable for SPI functionality. You need to appropriately
modify any such source code sections.
Version info Available as of DLL 600, OUT 600, RBF 600.
References mcbsp_init, set_mcbsp_freq
