Ctrl Command get_standby
Function Returns the currently set standby parameters.
Call get_standby( &HalfPeriod, &PulseLength )
Returned
parameter
values
HalfPeriod Half of the currently set standby output period of the standby pulses.
As a pointer to an unsigned 32-bit value.
1 bit equals 1/64 µs.
PulseLength Currently set pulse length of the standby pulses.
As a pointer to an unsigned 32-bit value.
1 bit equals 1/64 µs.
Comments • For usage of get_standby, see Section ”Signals for “Laser Standby” Operation”,
page 186.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 divides the values for HalfPeriod and PulseLength
by 8.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_standby
