Scanlab RTC6 PCIe Board - Park_Return_1_Axis

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
569
innovators for industry
Variable
List Command
park_return_1_axis
Function “Fly Extension” Command: Moves the output position for 1 Axis with jump speed from the
intermediate parking position to the specified absolute position in the 2D Image Field.
Restriction If the Option Processing-on-the-fly is not enabled, then park_return_1_axis only
carries-out the jump to the specified new output position.
Call park_return_1_axis( Mode, Axis, RetPos )
Parameters Mode = 0: Return position is ignored.
> 0: Return position. Absolute coordinate in the virtual Image Field.
As an unsigned 32-bit value.
Axis Axis from Table 3, page 259.
As an unsigned 32-bit value.
Allowed values: 1 … 2 .
RetPos Absolute axis coordinate of the new output position. In bits.
As a signed 32-bit value.
Out-of-range values are clipped to the boundary values.
Comments • Being an “Fly Extension” Command, park_return_1_axis must not be used mixed with
“Classic“ Processing-on-the-fly commands (see Footnote, page 242).
• See Chapter 8.6 ”Processing-on-the-fly”, page 242 and Section
”“Fly Extension” Commands”, page 259.
• See also comments on park_return.
• park_return_1_axis can be used to jump back to park_position_1_axis.
• If a Processing-on-the-fly correction has been previously deactivated at the specified
axis by park_position_1_axis ( Mode = 0 ) or park_position_2_axes ( Mode = 0 ) then
park_return_1_axis switches it back on again.
• With an unallowed parameter value, park_return_1_axis is replaced by a list_nop
(get_last_error return code RTC6_PARAM_ERROR ).
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 617, OUT 617, RBF 623.
References park_return_2_axes
