Scanlab RTC6 PCIe Board - Load_Jump_Table

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
502
innovators for industry
Comments
(cont’d)
• load_fly_2d_table is not executed (get_last_error return code RTC6_BUSY ), if:
– the BUSY list execution status is set
– the INTERNAL-BUSY list execution status is set
• load_fly_2d_table is even executed, if:
– a list has been paused by set_wait (PAUSED list execution status set)
• During the runtime of load_fly_2d_table, External Starts are suppressed.
• Before loading a table, load_fly_2d_table performs a DSP memory check that
produces error code 4 in case of error.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Additional: 2 tables can now be loaded simultaneously.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_fly_2d, init_fly_2d, get_fly_2d_offset
Ctrl Command load_fly_2d_table
Ctrl Command load_jump_table
Function Loads a value table with Jump Delay data points from an ASCII text file (or alternatively
performs automatic determination on the attached scan system) and uses linear
interpolation to create the internal Jump Delay table for 2D jumps executable in
Jump Mode.
Call NoOfDataPoints = load_jump_table( Name, No, PosAck, MinDelay, MaxDelay, ListPos )
Parameters Name See load_jump_table_offset.
No See load_jump_table_offset.
PosAck See load_jump_table_offset.
MinDelay See load_jump_table_offset.
MaxDelay See load_jump_table_offset.
ListPos See load_jump_table_offset.
Result See load_jump_table_offset.
Comments • load_jump_table is identical to load_jump_table_offset with Offset = 0.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
Reference load_jump_table_offset
