Ctrl Command read_io_port
Function Returns the current state of the 16-bit digital input port on the EXTENSION 1
socket connector.
Call IOPort = read_io_port()
Result 16-bit value (DIGITAL IN0…DIGITAL IN15).
As an unsigned 32-bit value.
Comments • See Chapter 9.2.1 ”16-Bit Digital Input Port”, page 288.
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References write_io_port, write_io_port_mask, set_io_cond_list, clear_io_cond_list,
read_io_port_buffer, read_io_port_list
