Variable
List Command
select_cor_table_list
Function Like select_cor_table, but a list command.
Call select_cor_table_list( HeadA, HeadB )
Parameters HeadA Like select_cor_table.
HeadB Like select_cor_table.
Comments • See select_cor_table.
• Even though select_cor_table_list is a short list command, execution of the directly
following list command is delayed by a few clock cycles due to the intermediate jump
to the corrected galvanometer scanner position. The extent of this delay depends on
the assigned correction table’s content for the current galvanometer scanner position
(for example, (0|0) after load_program_file); but it is at least 10 µs, even if the
correction table does not specify a correction.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References select_cor_table
