Scanlab RTC6 PCIe Board - Set_Pulse_Picking_List; Set_Qswitch_Delay; Set_Qswitch_Delay_List

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
719
innovators for industry
Undelayed
Short List
Command
set_pulse_picking_list
Function Like set_pulse_picking, but a list command.
Call set_pulse_picking_list( No )
Parameters No Like set_pulse_picking.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_pulse_picking
Ctrl Command set_qswitch_delay
Function In the YAG modes, defines the delay length of the first Q-Switch pulse with reference to
the FirstPulseKiller signal, see also Figure 53.
Call set_qswitch_delay( Delay )
Parameters Delay Q-Switch delay. As an unsigned 32-bit value.
1 bit equals 1/64 µs.
Allowed value range: [0…(2
26
–1)].
Comments • Values over (2
26
–1) are clipped.
• The YAG modes are selectable by set_laser_mode ( [1, 2, 3 or 5] ).
• Also for YAG modes defined with set_laser_mode( [1-3] ), the length of the Q-Switch
delay can be subsequently changed by this command; and for YAG mode 2 also with
set_firstpulse_killer or set_firstpulse_killer_list.
RTC4RTC6 New command.
In RTC4 Compatibility Mode,the RTC5 multiplies the specified value for Delay by 8.
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_qswitch_delay_list, set_laser_control, set_laser_pulses_ctrl, set_laser_pulses,
set_laser_timing, set_firstpulse_killer, set_firstpulse_killer_list
Undelayed
Short List
Command
set_qswitch_delay_list
Function Like set_qswitch_delay, but a list command.
Call set_qswitch_delay_list( Delay )
Parameters Delay Like set_qswitch_delay.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_qswitch_delay
