Undelayed
Short List
Command
if_cond
Function Conditional command execution:
if_cond immediately executes the directly following list command, if the current IOvalue
at the EXTENSION 1 socket connector’s 16-bit digital input port meets the following
condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ).
Otherwise, this list command is skipped.
Call if_cond( Mask1, Mask0 )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 See Mask1 .
Comments • See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References if_not_cond, if_pin_cond, if_not_pin_cond
Undelayed
Short List
Command
if_fly_x_overflow
Function Conditional command execution for Processing-on-the-fly applications:
if_fly_x_overflow immediately executes the directly subsequent list command, if the
condition in accordance with Mode for the x axis has been fulfilled.
Otherwise, this list command is skipped.
Call if_fly_x_overflow( Mode )
Parameters Mode To-be-evaluated condition.
As a signed 32-bit value.
= 0: Some kind of boundary exceedance occurred
(error bit Bit #4 = 1 or error bit Bit #5 = 1).
> 0: An overflow occurred (error bit Bit #5 = 1).
< 0: An underflow occurred (error bit Bit #4 = 1).
Comments • For usage of if_fly_x_overflow, see Section ”Customer-Defined Monitoring Area”,
page 256.
• The error bits queried in accordance with Mode (error bit Bit #4 and/or error bit Bit #5)
are reset.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_marking_info, set_fly_limits, clear_fly_overflow, clear_fly_overflow_ctrl,
if_not_fly_x_overflow
