Normal List
Command
set_duty_cycle_table
Function Category: List Commands for a Restricted User Group only.
Sets a value in the lookup table for the pulse length.
Call set_duty_cycle_table( Index, DutyCycle )
Parameters Index Index in the lookup table for the pulse length.
Allowed value range: 0…10.
As an unsigned 32-bit value.
DutyCycle Duty Cycle. In per mille.
Allowed value range: 0…1,000.
As an unsigned 32-bit value.
Comments • The relationship between encoder frequency and laser frequency is defined as follows:
– Encoder frequency = Index × [ Fmax / 10]
• Within the lookup table, the values are linearly interpolated.
• The value for pulse length is set depending on the laser frequency:
– Pulse length = laser frequency × DutyCycle / 1,000
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 626, OUT 627.
References set_laser_timing_table, regulation3
