5 Installation and Start-Up
89
(7) If you want to use the signals on the
RTC6 PCIe Board socket connectors, then attach
the appropriate cables. SCANLAB recommends
installing additional slot covers with suitable
connectors. Then the signals are accessible even
when the PC housing is closed. All
RTC6 PCIe Board connectors and signals are
described in Chapter 4 ”RTC6 PCIe Board – Layout
and Interfaces”, page 64.
(8) Install the RTC6 PCIe Board into the PCIe slot.
Observe the instructions in the manual of your
PC
(1)
.
(9) Close the PC housing.
(10)Place the PC at its operational location and
connect all peripheral equipment.
(11)Connect the 9-pin D-SUB connector on the
RTC6 PCIe Board – using the XY2-100 Converter
(Accessory), if necessary – to the scan system by a
data cable, see Chapter 4.5 ”Interfaces to Scan
System”, page 67.
(12)Connect the 15-pin D-SUB connector on the
RTC6 PCIe Board to the laser by a suitable
interface, see Chapter 4.6 ”Interfaces for the
Laser and Peripheral Equipment”, page 73.
(13)If necessary, connect one or more of the
RTC6 PCIe Board socket connectors (using
additional slot covers, see above) to the laser, a
handling system or other supplementary
equipment of the overall system.
(14)Check all connections and turn on the PC.
5.3 Installing the
RTC6 Board Driver
To install the RTC6 board driver for Windows 10, 8, 7,
proceed as follows:
• After the RTC6 PCIe Board has been installed,
start the computer.
For Windows 7:
(1) If the “Add Hardware Wizard“ does not come up
automatically, call it from the Control Panel.
(2) In the “Add Hardware Wizard“ specify the folder
that includes the RTC6 board driver. During
installation, the operating system automatically
selects the appropriate driver file (32-bit or
64-bit).
(3) Run
ScanlabClassChecker.cmd
as Administrator
(part of the delivered RTC6 Software Package; see
there also the background information in
ReadMe_ScanlabClassChecker.pdf
).
(1) If several master/slave-synchronized RTC6 PCIe Boards
are to be used in a PC, then the boards must be
connected pairwise with each other by the
Master and
Slave connectors and installed in preferably
(recommended) adjacent PCIe slots, see also
Chapter 4.4 ”Master Socket Connector, Slave Socket
Connector”, page 66.
Notice!
• If on your PC an WDM technology-based
RTC3/4/5 board driver
– is yet installed or
– was installed and has been removed or
– you are not sure in this regard:
(1)Install the RTC6 board driver.
(2)Run
ScanlabClassChecker.cmd
as
Administrator (part of the delivered
software package; see there also the
background information in
ReadMe_ScanlabClassChecker.pdf
).
Step 2 can be skipped on brand new PCs
on which an RTC board driver never has
been installed.
