Ctrl Command set_default_pixel
Function Defines the pulse length default value for the default pixel that terminates Pixel Output
Mode.
Call set_default_pixel( PulseLength )
Parameters PulseLength Default pixel pulse length.
As an unsigned 32-bit value.
1 bit equals 1/64 µs.
Allowed value range: [0…(2
32
–1)].
Comments • In Pixel Output Mode, the pixel pulse length at the end of an image line (at the
beginning of the default pixel) gets set to the specified default value, see Chapter 8.7.4
”Synchronization”, page 268.
• When initializing (by load_program_file), the PulseLength default value is set to 0.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_port_default
Undelayed
Short List
Command
set_default_pixel_list
Function Like set_default_pixel, but a list command.
Call set_default_pixel_list( PulseLength )
Parameters PulseLength Like set_default_pixel.
Comments • See set_default_pixel.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_default_pixel, set_port_default
