Normal List
Command
regulation3
Function Category: List Commands for a Restricted User Group only.
Varies laser frequency and pulse length depending on encoder frequency.
Call regulation3( Fmax, Fmin )
Parameters Fmax Max. encoder frequency. In Hz.
Allowed value range: 10,000…1,000,000.
As an unsigned 32-bit value.
Fmin Switch-off frequency. In Hz.
Allowed value range: 10…[ Fmax / 10].
As an unsigned 32-bit value.
Comments • regulation3 is executed infinitely until list execution is stopped by stop_execution or
an external /STOP.
• For encoder frequency < Fmin the laser is switched off.
• An encoder frequency > Fmax is clipped to Fmax .
• The value for the laser frequency results from the lookup table of
set_laser_timing_table.
• The value for the pulse length results from the lookup table of set_duty_cycle_table.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 626, OUT 627.
References set_duty_cycle_table, set_laser_timing_table
