Ctrl Command get_table_para
Function Returns the value of the specified parameter from a currently loaded correction table.
Call TablePara = get_table_para( TableNo, ParaNo )
Parameters TableNo Number of the currently loaded correction table.
As an unsigned 32-bit value.
Allowed values: [1…8]. See also number_of_correction_tables.
ParaNo Number of the parameter.
As an unsigned 32-bit value.
Allowed values: 0…15. Assignment see Section ”ct5 Correction File Header”,
page 178.
Result Parameter value, see Section ”ct5 Correction File Header”, page 178.
As a 64-bit IEEE floating point value.
Comments • The parameter values can be read out by get_table_para from a currently loaded
correction table and by get_head_para from an assigned correction table and thus
directly incorporated into a user program, see Section ”ct5 Correction File Header”,
page 178.
• If the parameters TableNo and ParaNo are out of range, then the return value is 0
(get_last_error return code RTC6_PARAM_ERROR ).
• If no correction table with the specified number has been loaded, then the parameter
values are undefined.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References –
Ctrl Command get_temperature
Function Returns the current temperature of the RTC6 board.
Call Temp = get_temperature()
Parameters None.
Result Temperature of the RTC6 board. In degrees Celsius.
As a 64-bit IEEE floating point value.
Comments • Execution of get_temperature takes about 1 ms.
• Continuous readout of the analog voltage (after a read_analog_in call) is delayed by
get_temperature by about 0.1 ms, see Section ”Analog Input Ports”, page 86.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 631, OUT 632.
References –
