Scanlab RTC6 PCIe Board - Set_Mcbsp_X; Set_Mcbsp_X_List

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
700
innovators for industry
Ctrl Command set_mcbsp_x
Function Activates or deactivates X offset correction for “Local Online Positioning“ by the
McBSP interface.
Call set_mcbsp_x( Scale )
Parameters Scale As a 64-bit IEEE floating point value.
2
–26
< Scale < 2
26
: scaling factor (correction is activated).
Otherwise: correction is deactivated.
Comments • For “Local Online Positioning“, see Chapter 8.3.1 ”“Local Online Positioning“”,
page 228.
• With an McBSP input value of X
in
for the X offset correction, apply_mcbsp functions
like set_offset( …, XOffset,…) , whereby
XOffset (in bits) = Scale × X
in
XOffset values outside of [–524,288…+524,287] are clipped to the boundaries as long
as Scale × X
in
does not exceed the value range ±2
31
.
• The McBSP interface cannot be simultaneously used for an Online Positioning and
Processing-on-the-fly applications.
See also Section ”Notes”, page 230.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_mcbsp_x_list, set_mcbsp_y, set_mcbsp_rot, apply_mcbsp
Undelayed
Short List
Command
set_mcbsp_x_list
Function Like set_mcbsp_x, but a list command.
Call set_mcbsp_x_list( Scale )
Parameters Scale Like set_mcbsp_x.
Comments • See set_mcbsp_x.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_mcbsp_x
