10 RTC6 Commands
462
innovators for industry
Undelayed
Short List
Command
if_pin_cond
Function Conditional command execution:
if_pin_cond immediately executes the directly following list command, if the current
IOvalue at the LASER Connector’s 2-bit digital input port meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ).
Otherwise, this list command is skipped.
Call if_pin_cond( Mask1, Mask0 )
Parameters Mask1 2-bit mask.
As an unsigned 32-bit value.
Only the lower 2 bits are evaluated.
Mask0 See Mask1 .
Comments • See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References if_not_pin_cond, if_cond, if_not_cond
