Ctrl Command set_offset
Function Defines:
• The offset for coordinate transformations, see Chapter 8.2 ”Coordinate
Transformations”, page 224.
• The global offset in virtual Image Field, see Section ”Coordinate Transformations in the
Virtual Image Field”, page 169
Call set_offset( HeadNo, XOffset, YOffset, at_once )
Parameters HeadNo See set_offset_xyz.
XOffset See set_offset_xyz.
YOffset See set_offset_xyz.
at_once See set_offset_xyz.
Comments • set_offset has the same effect as set_offset_xyz, but leaves ZOffset unchanged.
RTC4RTC6 Unchanged first functionality (offset definition).
See set_offset_xyz.
RTC5RTC6 Unchanged functionality.
See set_offset_xyz.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_offset_list, set_offset_xyz, set_angle, set_matrix, set_scale
Variable
List Command
set_offset_list
Function Like set_offset_xyz, but a list command.
Call set_offset_list( HeadNo, XOffset, YOffset, at_once )
Parameters HeadNo Like set_offset_xyz. However, HeadNo = 4 is not available.
XOffset Like set_offset_xyz.
YOffset Like set_offset_xyz.
at_once Like set_offset_xyz_list.
RTC4RTC6 See set_offset_xyz.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_offset_xyz
