Ctrl Command set_scanahead_speed_control
Function Only for scan systems with SCANahead technology, for example, the excelliSCAN.
Controls the Scanner Delays either depending on the target speed or actual achievable
speed.
Call set_scanahead_speed_control( Mode )
Parameters Mode Modus.
As an unsigned 32-bit value.
Comments • Mode with:
– Bit #0 controls mark commands
– Bit #1 controls jump commands
– Bit #n = 0 controls the Scanner Delays depending on the target speed
– Bit #n = 1 controls the Scanner Delays depending on the actual
achievable speed
• Default after load_program_file: Mode = 2.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of version DLL 610, OUT 610.
Last change with version OUT 611: adjustment of Laser Delays.
References –
