Normal List
Command
para_mark_rel_3d
Function Moves the laser focus at mark speed along a 3D vector from the current position to the
specified position (relative coordinate values) within the 3D Image Field. Simultaneously
varies the signal parameter selected by set_vector_control linearly to the specified value.
Restriction If the Option “3D” is not enabled or no 3D correction table has been assigned (see
select_cor_table), then para_mark_rel_3d has the same effect as para_mark_rel.
However, split-up into Microsteps is calculated like a 3D command and hence influences
the effective mark speed in the xy plane.
Call para_mark_rel_3d( dX, dY, dZ, P )
Parameters dX Relative x coordinate of the mark vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456…+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual Image Field for example,
for (enabled) Processing-on-the-fly applications.
dY Like X (analogously).
dZ Like X (analogously), except
Allowed value range: [–524,288…+524,287].
P End value of the signal parameter.
As an unsigned 32-bit value.
Allowed values: dependent on the selection made by set_vector_control
( Ctrl parameter), identical with set_vector_control ( Value parameter).
Comments • The coordinates for the mark vector end point are to be supplied as relative coordinates
with respect to the current position. Otherwise, para_mark_rel_3d is identical to
para_mark_abs_3d (see comments there).
• P is not treated on a relative basis.
• [*]para_mark[*] commands generally do not take Sky Writing into account.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for dX and dY by 16.
The allowed value range decreases accordingly. For the parameter P , see para_jump_abs.
RTC5RTC6 Unchanged functionality.
For the parameter P , see para_jump_abs.
Version info Available as of DLL 600, OUT 600, RBF 600.
References mark_rel_3d, set_vector_
control, para_mark_abs_3d,
para_mark_rel
