10 RTC6 Commands
568
innovators for industry
Comments
(cont’d)
• If the laser focus has not been previously moved to a safe area by park_position, then
park_return is a short list command with no further effect.
• If no Processing-on-the-fly mode has been previously active or if any
Processing-on-the-fly mode is currently active, then park_return performs a normal
jump to the specified location.
• If a coordinate transformation in the virtual Image Field is active, then the specified or
most recent valid position is subsequently appropriately transformed (see Section
”Coordinate Transformations in the Virtual Image Field”, page 169).
• After park_return, a Jump Delay is activated.
• park_return switches off the Signals for “Laser Active” Operation after a
LaserOff Delay.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified coordinate values by 16.
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References park_position
Variable
List Command
park_return
